Elsa 9-Space Bike Rack
Product code: UF-MAST108
The Elsa 9-Space Bike Rack is a surface-mounted steel rack with nine cycle spaces across a width of 348 cm. The spaces can be set at an angle of 90 or 45 degrees. It is suitable for cycle parking at schools, public offices, sports facilities, housing estates and business premises.
Product description
- 9 bike spaces across a width of 348 cm
- Bike spaces at 90 or 45 degrees
- Bikes positioned at an angle or perpendicular
- Galvanised, painted or stainless steel
- 8 fixing plugs and screws included
Stojak rowerowy Elsa 9 stanowisk mieści dziewięć rowerów w odstępach co 42 cm. Ma 348 cm szerokości, 42 cm wysokości i 56 cm głębokości. Pasuje na większe parkingi rowerowe przy szkołach, urzędach i obiektach sportowych, a także na osiedla i do firm.
Stanowiska ustawiacie pod kątem 90 albo 45 stopni. Rowery mogą więc stać prostopadle albo skośnie. Konstrukcja jest z profilu 30 x 30 x 1,5 mm i rurki o przekroju 18 mm i grubości ścianki 2 mm.
Do wyboru są wykończenia: stal ocynkowana, stal ocynkowana i malowana albo stal nierdzewna. Wariant ustalimy z Wami indywidualnie. Stojak przykręca się do podłoża ośmioma kołkami rozporowymi, które są w zestawie.
- liczba stanowisk: 9
- szerokość stanowiska: 6,5 cm
- waga: 31 kg
- montaż: 8 kołków Ø 10 x 100 mm, śruby Ø 7 x 107 mm, klucz SW13 lub T40
Specification
| number of bike spaces | 9 |
| rack/hanger width | 348cm |
| height | 42cm |
| depth | 56cm |
| bike space width | 6.5cm |
| spacing between bike spaces | 42cm |
| tube diameter | 18mm |
| tube wall thickness | 2mm |
| rack profile | 30x30x1.5mm |
| material | galvanised steel, galvanised and painted steel, stainless steel |
| bike space adjustment | adjustable (90 and 45 degrees) |
| fixing method | to the ground |
| installation method | bolt-down |
| weight | 31kg |
| installation | 8 expansion anchors Ø 10x100mm for Ø 7x107mm screws (included), for SW13 spanner or T40 bit |
| bike space arrangement | angled or perpendicular |
