Elsa 19-Space Bike Rack
Product code: UF-MAST162
The Elsa 19-space bike rack is a single-sided steel rack for 19 bicycles, 768 cm long. It is bolted to the ground, and the spaces can be set perpendicular or angled. It is ideal wherever large numbers of bicycles are parked every day.
Product description
- 19 stands over a length of 768 cm
- Single-sided parking
- Bike spaces at 90 or 45 degrees
- Galvanised finish, other options available
- Weight 65 kg
Stojak rowerowy Elsa 19 stanowisk to rozwiązanie dla szkół, urzędów, biurowców i osiedli, gdzie potrzeba wielu miejsc dla rowerów w jednym rzędzie. Na długości 768 cm mieści 19 rowerów parkowanych z jednej strony, w rozstawie 42 cm.
Stanowiska ustawicie pod kątem 90 lub 45 stopni. Konstrukcję tworzy profil 30x30x1,5 mm i rurki 18 mm o ściance 2 mm. Stojak ma powłokę ocynkowaną, a w ofercie są też warianty ocynkowany i malowany oraz ze stali nierdzewnej. Wykończenie ustalimy z Wami indywidualnie.
Stojak przykręca się do podłoża. W zestawie jest 16 kołków rozporowych Ø 10x100 mm ze śrubami Ø 7x107 mm pod klucz SW13 lub T40.
- liczba stanowisk: 19
- szerokość: 768 cm, wysokość: 42 cm, głębokość: 56 cm
- szerokość stanowiska: 6,5 cm
- waga: 65 kg
Specification
| number of bike spaces | 19 |
| rack/hanger width | 768cm |
| height | 42cm |
| depth | 56cm |
| bike space width | 6.5cm |
| spacing between bike spaces | 42cm |
| tube diameter | 18mm |
| tube wall thickness | 2mm |
| rack profile | 30x30x1.5mm |
| rack finish | galvanised |
| material | galvanised steel, galvanised and painted steel, stainless steel |
| bike space adjustment | adjustable (90 and 45 degrees) |
| parking arrangement | single-sided |
| fixing method | to the ground |
| installation method | bolt-down |
| weight | 65kg |
| installation | 16 expansion anchors Ø 10x100mm for Ø 7x107mm bolts (included), for SW13 or T40 tools |
| bike space arrangement | angled or perpendicular |
