Elsa 17-Space Bike Rack
Product code: UF-MAST150
The Elsa 17-Space Bike Rack is a 684 cm wide steel structure for 17 bicycles, bolted to the ground. The spaces can be set perpendicular or at an angle, and bicycles are parked from one side. Suitable for schools, public offices, office buildings and housing estates.
Product description
- 17 stands over a length of 684 cm
- Spaces set at a 90 or 45 degree angle
- Galvanised, painted or stainless steel
- 16 expansion anchors with bolts included
- Weight 58 kg
Stojak rowerowy Elsa 17 stanowisk to długi, niski stojak do miejsc, gdzie codziennie parkuje wiele rowerów: przy szkołach, urzędach, biurowcach, osiedlach i obiektach publicznych. Rowery wstawia się jednostronnie, a stanowiska można ustawić pod kątem 90 lub 45 stopni, czyli prostopadle albo skośnie.
Konstrukcję tworzy profil 30x30x1,5 mm i rurki o przekroju 18 mm przy ściance 2 mm. Stojak jest dostępny w stali ocynkowanej, ocynkowanej i malowanej albo nierdzewnej. Stal nierdzewna nie wymaga malowania i dobrze znosi wilgoć oraz sól drogową. Wariant wykończenia ustalimy z Wami indywidualnie.
Stojak przykręca się do podłoża. W zestawie jest 16 kołków rozporowych Ø 10x100 mm ze śrubami Ø 7x107 mm pod klucz SW13 lub T40.
- liczba stanowisk: 17
- szerokość: 684 cm, wysokość: 42 cm, głębokość: 56 cm
- szerokość stanowiska: 6,5 cm, rozstaw: 42 cm
- waga: 58 kg
Specification
| number of bike spaces | 17 |
| rack/hanger width | 684cm |
| height | 42cm |
| depth | 56cm |
| bike space width | 6.5cm |
| spacing between bike spaces | 42cm |
| tube diameter | 18mm |
| tube wall thickness | 2mm |
| rack profile | 30x30x1.5mm |
| material | galvanised steel, galvanised and painted steel, stainless steel |
| bike space adjustment | adjustable (90 and 45 degrees) |
| parking arrangement | single-sided |
| fixing method | to the ground |
| installation method | bolt-down |
| weight | 58kg |
| installation | 16 expansion anchors Ø 10x100mm for Ø 7x107mm bolts (included), for SW13 or T40 tools |
| bike space arrangement | angled or perpendicular |
