Kornel wall-mounted bike rack, 7 spaces
Product code: UF-MAST244
The Kornel wall-mounted bike rack, 7 spaces, is a steel hanger fixed to a wall that holds 7 bicycles. With a depth of only 30 cm, it is suitable where there is no room for a freestanding rack, and the angle of the spaces is adjustable.
Product description
- 7 wall-mounted spaces
- Angle adjustable from 90 to 45 degrees
- Depth of only 30 cm
- 8 anchors and screws included
- Weight 20 kg
Stojak rowerowy Kornel 7 stanowisk ścienny mocuje się bezpośrednio do ściany, dzięki czemu nie zajmuje podłogi. Przy szerokości 264 cm mieści siedem rowerów, a wystaje ze ściany tylko na 30 cm.
Stanowiska o szerokości 6,5 cm rozstawiono co 42 cm. Ich kąt ustawia się w zakresie od 90 do 45 stopni, więc rowery mogą stać prostopadle lub skośnie, co ułatwia mieszczenie kierownic obok siebie. Konstrukcja powstała z profilu 30x30x1,5 mm i rurek 18 mm o ściance 2 mm.
Stojak jest dostępny ze stali ocynkowanej, ocynkowanej i malowanej albo nierdzewnej. W zestawie jest 8 kołków rozporowych Ø 10x80 mm ze śrubami Ø 7x80 mm, dokręcanymi kluczem SW13 lub T40. Ściana musi być stabilna i nośna. Wykończenie ustalimy indywidualnie.
- Wymiary: 264 × 30 cm, wysokość 48 cm
- Waga: 20 kg
Specification
| number of bike spaces | 7 |
| rack/hanger width | 264cm |
| rack height | 48cm |
| rack depth | 30cm |
| bike space width | 6.5cm |
| spacing between bike spaces | 42cm |
| tube diameter | 18mm |
| tube wall thickness | 2mm |
| rack profile | 30x30x1.5mm |
| material | galvanised steel, galvanised and painted steel, stainless steel |
| bike space adjustment | range from 90 to 45 degrees |
| fixing method | to wall |
| installation method | bolt-down |
| weight | 20kg |
| installation | 8 expansion anchors Ø 10x80mm for Ø 7x80mm screws (included), SW13 or T40 drive |
| bike space arrangement | angled or perpendicular |
