Kornel wall-mounted bike rack, 6 spaces
Product code: UF-MAST247
The Kornel wall-mounted bike rack, 6 spaces, is a steel hanger mounted on a wall that holds 6 bicycles. The angle of the spaces can be set between 90 and 45 degrees. The rack is suitable for garages, underground car parks, narrow passageways and building façades.
Product description
- 6 spaces at 42 cm centres
- Angle adjustable from 90 to 45 degrees
- Wall-mounted, 8 anchors included
- Width 222 cm, weight 17 kg
- Galvanised, painted or stainless steel
Stojak rowerowy Kornel 6 stanowisk ścienny mocuje się do ściany, dzięki czemu nie zajmuje podłogi. Przyda się tam, gdzie brakuje miejsca na stojak wolnostojący: w garażach, na parkingach podziemnych, w wąskich przejściach i przy elewacjach budynków.
Stojak ma 6 stanowisk o szerokości 6,5 cm rozstawionych co 42 cm. Kąt stanowisk ustawicie w zakresie od 90 do 45 stopni, a rowery mogą stać skośnie lub prostopadle do ściany. Konstrukcję wykonano z profili 30x30x1,5 mm i rurek 18 mm o ściance 2 mm. Do wyboru jest stal ocynkowana, ocynkowana i malowana albo nierdzewna.
Do montażu potrzebna jest stabilna, nośna ściana. W zestawie dostajecie 8 kołków rozporowych Ø 10x80 mm i śruby Ø 7x80 mm pod klucz SW13 lub bit T40. Wykończenie ustalimy z Wami indywidualnie.
- Wymiary: szerokość 222 cm, wysokość 48 cm, głębokość 30 cm
- Regulacja kąta: od 90 do 45 stopni
- Waga: 17 kg
Specification
| number of bike spaces | 6 |
| rack/hanger width | 222cm |
| rack height | 48cm |
| rack depth | 30cm |
| bike space width | 6.5cm |
| spacing between bike spaces | 42cm |
| tube diameter | 18mm |
| tube wall thickness | 2mm |
| rack profile | 30x30x1.5mm |
| rack finish | galvanised |
| material | galvanised steel, galvanised and painted steel, stainless steel |
| bike space adjustment | range from 90 to 45 degrees |
| fixing method | to wall |
| installation method | bolt-down |
| weight | 17kg |
| installation | 8 expansion anchors Ø 10x80mm for Ø 7x80mm screws (included), SW13 or T40 drive |
| bike space arrangement | angled or perpendicular |
