Kornel 5-Space Wall-Mounted Bike Rack
Product code: UF-MAST178
The Kornel 5-Space Wall-Mounted Bike Rack is a galvanised steel rack bolted to a wall. It holds five bicycles, and the angle of the spaces can be adjusted from 45 to 90 degrees. It works well where there is not enough room for a free-standing rack.
Product description
- Wall-mounted, depth only 30 cm
- Bike space angle adjustable from 45 to 90°
- 5 bike spaces at 42 cm spacing
- Galvanised steel, weight 14 kg
Stojak rowerowy Kornel 5 stanowisk ścienny montuje się na ścianie, dzięki czemu zajmuje mało miejsca przed budynkiem. Ma tylko 30 cm głębokości, a pięć stanowisk rozmieszczono co 42 cm na szerokości 180 cm.
Stanowiska mają regulację kąta od 90 do 45 stopni. Rowery mogą więc stać prostopadle do ściany albo skośnie, co przydaje się w wąskich przejściach. Konstrukcja ze stali ocynkowanej łączy profil 30 x 30 x 1,5 mm z rurką 18 mm o grubości ścianki 2 mm.
Do montażu służą 4 kołki rozporowe Ø 10 x 100 mm ze śrubami Ø 7 x 107 mm pod klucz SW13 lub T40. Elementy są w zestawie. Stojak nadaje się do osiedli, szkół, zakładów pracy i obiektów sportowych.
- wymiary: szerokość 180 cm, wysokość 48 cm, głębokość 30 cm
- szerokość stanowiska: 6,5 cm
- waga: 14 kg
Specification
| number of bike spaces | 5 |
| rack/hanger width | 180cm |
| rack height | 48cm |
| rack depth | 30cm |
| bike space width | 6.5cm |
| spacing between bike spaces | 42cm |
| tube diameter | 18mm |
| tube wall thickness | 2mm |
| rack profile | 30x30x1.5mm |
| rack finish | galvanised |
| material | galvanised steel |
| bike space adjustment | range from 90 to 45 degrees |
| fixing method | to wall |
| installation method | bolt-down |
| weight | 14kg |
| installation | 4 expansion anchors Ø 10x100mm for Ø 7x107mm screws (included), for SW13 spanner or T40 bit |
| bike space arrangement | angled or perpendicular |
