Kasper 12-Space Bike Rack with Rails
Product code: UF-MAST527
The Kasper 12-space bike rack with rails is a steel rack for 12 bicycles parked perpendicularly, with rails made of Ø 25 mm tube. It is 474 cm wide and 85 cm deep and is bolted to the ground. It is ideal for organising bicycle parking at schools, public offices or on housing estates.
Product description
- 12 perpendicular bays
- Rails made of Ø 25 mm tubing
- Width 474 cm, depth 85 cm
- Choice of three steel variants
- 22 anchors and bolts included
Stojak rowerowy Kasper 12 stanowisk z barierkami mieści 12 rowerów ustawionych prostopadle obok siebie. Przy szkołach, urzędach i na osiedlach pozwala uporządkować miejsce, w którym zostawia się rowery.
Konstrukcję tworzy profil 30x30x1,5 mm i rurka nośna o przekroju 18 mm ze ścianką 2 mm. Barierki wykonano z rurki Ø 25 mm. Wysokość stojaka wynosi od 45 do 80 cm. Głębokość 85 cm daje więcej miejsca przy wprowadzaniu roweru. Stojak może być ze stali ocynkowanej, ze stali ocynkowanej i malowanej albo ze stali nierdzewnej. Wariant materiału ustalimy z Wami indywidualnie.
Stojak przykręca się do twardego podłoża. W zestawie jest 22 kołków rozporowych Ø 10x80 mm i śruby Ø 7x80 mm pod klucz SW13 lub bit T40.
- liczba stanowisk: 12, nieregulowane
- wymiary: szer. 474 cm, wys. 45–80 cm, gł. 85 cm
- szerokość stanowiska: 6,5 cm, rozstaw: 42 cm
- waga: 77 kg
Specification
| number of bike spaces | 12 |
| rack/hanger width | 474cm |
| height | 45-80cm |
| depth | 85cm |
| bike space width | 6.5cm |
| spacing between bike spaces | 42cm |
| tube diameter | 18mm |
| tube wall thickness | 2mm |
| rack profile | 30x30x1.5mm |
| material | galvanised steel, galvanised and painted steel, stainless steel |
| bike space adjustment | non-adjustable |
| barrier tube cross-section | Ø 25mm |
| fixing method | to the ground |
| installation method | bolt-down |
| weight | 77kg |
| installation | 22 Ø 10x80mm expansion anchors for Ø 7x80mm screws (included), SW13 or T40 drive |
| bike space arrangement | perpendicular |
